| CPU |
Intel® Cedar Trail ™ Dual Core Processor |
| Core Logic |
Intel® NM10 Express Chipset |
| Display |
10.1" (25.65cm) WSVGA (1024x600) |
| Memory |
Single channel DDR3
One 200Pin SODIMM socket, support for DDR3 1066/1333 MHz
Expandable memory up to 4GB, depends on 1GB/2GB SODIMM Module |
| Video Controller |
Intel® Graphics Media Accelerator 3650, Up to 1.7G |
| Storage |
One changeable 2.5" 9.5mm(H) HDD, SATA Interface
(Factory Option) External Super Multi ODD, USB Interface |
| Keyboard and Pointing Device |
Multi language
Built-in Touch pad with scrolling function |
| Audio |
High Definition Audio
Built-in microphone
Built-in two speakers |
| I/O Ports |
3x USB 2.0 ports
1x external CRT port
1x headphone jack
1x microphone jack
1x RJ-45 jack
1x DC-in jack |
| Card Reader |
8-in-1 Card Reader (MMC/RSMMC/SD/Mini SD/SDHC/MS/MS Pro/MS Duo) |
| Slots |
Two Mini Card slots
1st for WLAN half size Mini Card with PCIe interface
(Factory Option) 2nd for 3.75 half size Mini Card with USB interface |
| Communication |
Built in 10/100Mb Base-TX Ethernet LAN
300k pixel video camera
(Factory Option) Wireless LAN 802.11b/g/n half Mini Card module
(Factory Option) UMTS/HSPA 3.75G half Mini Card module
(Factory Option) Bluetooth v2.1 + EDR module
|
| Power Supply |
Full range AC adapter 30w, AC in 100~240V, 50~60Hz, DC output 19V, 1.58A
Removable 3 cells Smart Lithium-Ion battery pack, 24.42WH
(Factory Option) Removable 6 cells Smart Lithium-Ion battery pack, 48.84WH
Battery life: 270 minutes (with 24.42WH battery)
Battery life: 540 minutes (with 48.84WH battery) |
| Security |
Kensington Lock |
| Other design |
IMR |
| Operating System |
Windows 7
Windows XP (SP3) |
| Dimension |
266(W) x 185(D) x 19.7~27.1(H)mm |
| Weight |
0.93kg (with 24.42WH battery) |
