| Processor |
• 3rd generation Intel® Core™ i7 Quad Core processor
• 3rd generation Intel® Core™ i7/ i5 Duo Core processor
• 2nd generation Intel® Core™ i7/i5/i3 processor
|
| Core Logic |
• Mobile Intel® HM76 Express Chipset |
| Display |
• 17.3” (43.94cm) HD+(1600X900) 16:9 Crystal Bright Screen
• 17.3” (43.94cm) FHD(1920X1080) 16:9 Crystal Bright Screen |
| Memory |
• Dual channel DDR3
• Two 204 pins SODIMM sockets, support DDR3 1333/1600MHz (Real operation frequency depends on processor)
• Expandable memory up to 8GB, depends on 1GB/2GB/4GB SODIMM module |
| Video Controller |
• Intel® HD Graphics 3000(GPU type Depends on Processor)
- Dynamic frequency
- Intel Dynamic Video Memory Technology up to 1.7GB
- Microsoft DirectX® 10 compatible
• nVIDIA® GeForce GT 630M (N13P-GL)
- 1GB DDR3 Video RAM
- Support PCIe x 8
- Microsoft® DirectX® 11 compatible
- nVIDIA PhysX™
- GeForce CUDA™ Technology
- nVIDIA® Optimus 2012 Technology
• GPU switchable between iGPU and dGPU |
| Storage |
• (Factory option) One changeable 12.7mm(H) Super Multi / Blu-ray Combo ODD, SATA interface
• One changeable 2.5” 9.5 mm(H) HDD, SATA interface
|
| Audio |
• High Definition Audio
• Built in microphone
• Built in two speakers
• THX TruStudio Pro |
| Keyboard & Pointing Device |
• Multi language full size isolated keyboard with numeric pad
• Built in touch pad with multi-gesture and scrolling function
|
| I/O ports |
• 1 x USB 2.0 port
• 2 x USB 3.0 ports
• 1 x eSATA port
• 1 x external VGA port
• 1 x HDMI 1.4a output port (with HDCP)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack
|
| Card Reader |
• 9-in-1 card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC
- MS / MS Pro / MS Duo |
| Slot |
• One Mini Card slots
• 1st for WLAN Combo Half size Mini Card with PCIe and USB interface |
| Communication |
• Built-in 10/100/1000Mb Base-T Ethernet LAN
• (Factory option) Intel® next generation WLAN
• (Factory Option) Wireless LAN 802.11B/G/N + Bluetooth v3.0+HS Combo Half Mini Card module
• (Factory Option) Wireless LAN 802.11B/G/N Half Mini Card module
• (Factory Option) 1.3M/2.0M pixels video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V, 4.74A, 90W
• Removable 6 cells Smart Lithium-Ion battery pack, 48.84WH
• (Factory Option) Removable 6 cells Smart Lithium-Ion battery pack, 62.16WH
• Battery life : 280 minutes (UMA mode with 48.84WH battery)
• Battery life : 360 minutes (UMA mode with 62.16WH battery)
|
| Security |
• Kensington® Lock |
| Others Design |
• IMR
• Intel® Anti-Theft Technology
• Intel® Smart Connect Technology |
| O.S. Support |
• Windows® 7 (SP1) |
| Certificate |
• Windows® 7 (64-bit) Logo |
| Dimensions |
• 413(W) X 270(D) X 14~40.5(H)mm |
| Weight |
• 3kg (TBC) including ODD and 48.84WH Battery |
