| System |
Intel® Core™ i5-7300U vPro™ processor 2.6GHz
Intel® Core™ i5-8250U processor 1.6GHz
8GB DDR4 SDRAM, 16GB DDR4 SDRAM (By request)
128GB M.2 SSD, 256GB M.2 SSD (By request)
|
| Operating System |
OS options : Windws 10 IoT Enterprise, Windows 10 Pro |
| Display |
10.1” WUXGA (1920 x 1200) TFT LCD, Gorilla Glass
850 nits sunlight readable with hyper dimming option
Capacitie multi-ouch screen supports glove touch, water rejection, palmrejection, 2mm had tip tylus
Optional digiter with IP54 pen |
| I/O Interface |
USB 3.1 type A x 1, USB 3.1 type C x 1
RS-232 x 1, option USB 2.0 or Mico SD slot
Audio headset jack (Headphone/ microphone combo) x 1
Micro SIM slot x 1, Micro HDMI x 1
Optional RF pass-though connector for WLAN/ GNSS/ WWAN x 2
Docking connector (12-pin) x 1
DC-in x 1 |
| RF |
Gigabit Ethernet (RJ45)
Wi-Fi 802.11 a/b/g/n/ac
Bluetooth V4.2
GNSS (GPS/GLONASS/BeiDou)
Optional 4G LTE |
| Webcam |
Front: 2MP
Rear: 8MP with auto focus and LED flash |
| Expansion Option |
Built-in 2D barcode reader (OCR option)
NFC + Smart card reader module
Fingerprint reader, UHF RFID reader, 3D camera by request
Snap-on connector easy for customization |
| Rugged Features |
IP65 and MIL-STD-810G certifie
Vibration, shock and 5-foot drop resistance |
| Battery |
4500 mAh hot swappable battery, 12 hours battery life *
Optional 9000 mAh hot swappable battery, up to 23 hours battery life *
Fast charging supported
*Listed battery life is based on MobileMark 2014® productivity mode testing with wieless on. Battery life rating is or comparison purposes only. Actual battery |
| Security |
TPM2.0
Phoenix SecureWipe by request |
| Control Button |
Programmable button x 3
Power, volume, Windows button
Barcode trigger x 1 |
| LED Indicator |
Power on/off
Battery full/charging/low
Wi-Fi on/off
Fn on/off |
| Sensor |
Gyroscope, G-sensor, E-compass, light sensor |
| Power Adapter |
AC adapter (65W, 100-240V AC, 50/60Hz) |
| Environment |
Operating temperature -20°C to 60°C
Storage temperature -30°C to +70°C
Humidity 5%~95% non-condensing
|
| Software |
DsahON |
| In-box Accessory |
Digitizer pen
Handle
Hand strap
Shoulder strap
Power adapter |
| Weight |
1.36 kg (3.0 lbs) |
| Dimensions |
28 x 19.5 x 2.3 cm (11” x 7.7” x 0.9”) (W x H x D) |
