| CPU Support |
Intel® Atom™ BayTrail processors |
| Memory |
1x DDR3L SODIMM |
| Graphics |
Intel® HD Graphics |
| BIOS |
AMI Plug & Play SPI BIOS |
| Display |
Display Size: 17 inch, 4:3
Resolution: 1024 x 768
Backlight: LED
Contrast Ratio: 600:1 (typical)
Brightness: 350 cd/m² (typical) |
| External Display |
1x HDMI
1x VGA |
| Touch Sensor |
5-wire resistive touch sensor |
| LAN |
2x Gigabit Ethernet (Realtek RTL8111G)
PXE/WOL supported |
| Audio |
Realtek ALC662 HD Codec w/ 2W Audio Amplifier
Line-In, Line-Out and Mic-In Supported |
| Storage |
1x 2.5” SATA HDD or SSD space |
| USB |
4x USB 2.0, 1x USB 3.0 |
| COM |
2x COM ports with RS-232/422/485 selection supported |
| Expansion Slot |
1x mPCIe slot |
| Hardware Monitor |
Operating voltage, CPU temperature |
| Watchdog Timer |
1-255 step, can be set with software on Super I/O |
| Power |
DC 12V input |
| O/S Support |
Windows 10 |
| Dimension (W x H x D) |
410 x 315 x 58 mm / 16.14” x 12.40” x 2.28” |
| Environment |
Operation Temperature:
0°C ~ 60°C / 32°F ~ 140°F (SSD)
0°C ~ 50°C / 32°F ~ 122°F (2.5” HDD)
Storage Temperature: -20°C ~ 70°C / -4°F ~ 158°F
Humidity: 0% ~ 95% non-condensing |
| Mounting |
VESA Mount, Panel Mount |
